GitHub - Coffeeri/malvm: Malvm is a tool to create modified Windows 10/ 7 virtual machines, where malware is not able to detect its virtual environment. Those VMs can be used to analyze malware.

Build non detectable Virtual Machines for malware analysis.

We currently only support Linux!

The tool malvm is used to create sanitized virtual environments, such that a malware is not able to determine, if it's in a virtual environment or not. Create and integrate your own analysis images:

Build: OS images with Packer and deploy them with Vagrant. All centralized controlled by malvm.
Configure: Set your settings such as logging and default VM configuration. Predefine your environment in malvm_config.yaml and build + deploy it with malvm up.
Integrate: Add your own characteristic fixes and let malvm run them inside your VM.
Extendable: The entire project is build very modular, you can integrate your own hypervisor, view and (sub-)controller.

Getting Started

Table of Content

Prerequisite

Please make sure that the following dependencies are installed:

Make sure your host runs on a linux os.
Python3
git
Vagrant
Packer (malvm v0.0.1 tested with packer 1.5.6; malvm v0.0.2 tested with packer 1.6.5)
VirtualBox

Install malvm

Please make sure that you have installed all packages in Prerequisite.

with pip

You need to create a personal access token.

Scope needed: read_api

pip install --extra-index-url https://YOUR_ACCESS_TOKEN_NAME:YOUR_ACCESS_TOKEN@gitlab.com/api/v4/projects/18734431/packages/pypi/simple malvm

with git clone and manual Installation

1. Clone the Repository and open a shell in the folder.

git clone git@gitlab.com:shk_fkie/analysevm.git

2. Install package

2.1 Install package (Normal User)

2.1 Install package (Developer)

First VM

In the following we are going to create a Windows 10 VM called "malwareVM". We use two commands chained together.

malvm box build windows_10
malvm box start malwareVM windows_10

First malware box build windows_10 builds the Windows 10 image for Vagrant. Next malvm box start malwareVM windows_10 spins up a Virtual Machine instance of the previously created image.

Both commands can be chained into a single command:

malvm box build windows_10 start malwareVM windows_10

Checks and Fixes

Malvm analyses its environment. It includes Characteristics which reveal the existence of being in a VM-environment.

Those characteristics can be checked with:

If those failed ones should be fixed, simply run:

Characteristics

malvm uses different characteristics, each having its own check and fix method. All Characteristic definitions are in src/malvm/characteristics/ defined. All modules in this package will be dynamically loaded.

Each Module defines a characteristic and consists of a class, which inherits from Characteristic class in src/malvm/characteristics/abstract_characteristic.py.

Each Characteristic-Module can have multiple Sub-Characteristics. In the example of FilesCharacteristic - each File would be its own Sub-Characteristic.

Configuration file

The configfile is usually located at ~/.local/share/malvm/malvm_config.yaml. You are able to configure syslog, logging path and Base Images/ Virtual Machines. A default Virtual Machine has to exist at any time, which will be used for malvm box start ... After configuring malvm_config.yaml you are able to build and defined Base Images/ VMs via the command malvm up.

Note:

disk_size needs a size prefix such as GB
memory does not need a prefix, it is MB by default

Example

logging:
  syslog_address: /dev/log
  rotating_file_path: ~/.local/share/malvm/logs/malvm.log
base_images:
  malvm-win-10:
    template: windows_10
    username: max
    password: 123456
    computer_name: Computer
    language_code: de-De
virtual_machines:
  default:
    base_image: malvm-win-10
    disk_size: 120GB
    memory: 2048
    choco_applications: [ ]
    pip_applications: [ ]
  fkieVM:
    base_image: malvm-win-10
    disk_size: 120GB
    memory: 4096
    choco_applications: [adobereader, firefox, 7zip.install]
    pip_applications: [requests]
