Detiled - is a Defold library that converts Tiled maps and tilesets into Decore entities.

Features

• Load tilesets with prefab definitions and component properties
• Convert Tiled maps to Decore entities
• Use class names as prefab IDs, with fallback to image names
• Support for custom properties and components from Tiled

Setup

Open your game.project file and add the following line to the dependencies field under the project section:

Decore

https://github.com/Insality/decore/archive/refs/tags/3.zip

Detiled

https://github.com/Insality/detiled/archive/refs/tags/2.zip

After that, select Project ▸ Fetch Libraries to update library dependencies. This happens automatically whenever you open a project so you will only need to do this if the dependencies change without re-opening the project.

Library Size

Note: The library size is calculated based on the build report per platform

Setup

Workflow

1. Load all tilesets before loading maps:

   local detiled = require("detiled.detiled")

   -- Load all used tilesets first before loading maps
   detiled.load_tileset("/resources/tilesets/my_tileset.json")

2. Convert Tiled maps to Decore entities:

   -- Get entity prefab from map
   local map = detiled.get_entity_from_map("/resources/maps/my_map.json")

   -- Add to Decore world
   world:addEntity(decore.create(map))

Prefab ID Resolution

Prefab IDs are determined in this order:

1. class field from the tile or object in Tiled
2. type field as fallback
3. Image filename (without path/extension) as final fallback

Object Types

• Tile Objects - Objects with gid (from tileset) use tileset properties
• Class Objects - Objects with class field spawn as that prefab type
• Empty Objects - Objects without gid or class spawn as basic entities

Custom Properties

To override component properties from Tiled:

1. Setup Custom Types in Tiled:

   • Go to View -> Custom Types Editor
   • Add your custom class with the property name matching your component
   • Example: Create a movement class with stick (bool) and speed (int) properties

2. Use in Tilesets or Maps:

   • Add the custom property to tiles in tilesets or directly to object instances in maps
   • Properties with propertytype matching the property name become components

3. Property Override Hierarchy (highest priority first):

   • Map instance properties
   • Tileset properties
   • Entity definition properties
   • Default Decore component values

Example: If an entity has movement = { can_jump = true, speed = 20 } by default, you can override just the speed in Tiled while keeping can_jump = true.

Layer Properties

Layers support special properties:

• position_z - Sets the Z position for all entities spawned from this layer
• Objects can have their own position_z property that gets added to the layer's position_z

Game Example

Look at Shooting Circles or Cosmic Dash game examples to see how to use the Detiled library in a real game project.

API Reference

Quick API Reference

detiled.set_logger(logger_instance)
detiled.load_tileset(tileset_path_or_data)
detiled.get_entity_from_map(map_path_or_data)

API Reference

Read the API Reference file to see the full API documentation for the module.

License

This project is licensed under the MIT License - see the LICENSE file for details.

Issues and Suggestions

For any issues, questions, or suggestions, please create an issue.

👏 Contributors

Changelog

- Reworked API and documentation
