GitHub - MonarchStore/monarchs: A hierarchical, NoSQL, in-memory data store with a RESTful API

A hierarchical, NoSQL, in-memory data store with a RESTful API.

A hierarchical data store is a service which facilitates CRUD actions on data organized in a tree structure with a pre-determined depth.

An example domain may define these relationships:

Continents have countries
Countries may have states (or provinces)
States have cities

The hierarchy is then defined as:

graph TD;
continents --> countries --> states --> cities

A hierarchical data store enforces rules to maintain the integrity of the tree structure. All elements need have a parent of the pre-defined type. In our example domain described above, countries cannot exist without a parent continent, and cities cannot be created as direct children of a country.

A hierarchical data store makes it easy to query the stored entities at any depth and retrieve the parent nodes or the children nodes in a single request. For example, to get a country's properties along with the states of that country and the cities in those states, send a request with the countries label, the country's ID and the depth parameter set to 2.

Why use a hierarchical data store?

Some applications can represent their data model as a hierarchy. A specialized data store can take advantage of optimized data structures for fast reads. A hierarchichal data store also provides a simple interface to write and query nodes in the hierarchy. This reduces code complexity and development time.

How does MonarchStore compare against a relational database?

Relational databases, such as MySQL or PostgreSQL, can be slow, since joins are computed at query time. Moreover, they often require the application to make a trade-off between making multiple round trips or repeating the joinned data when a query involves many tables. A hierarchical database can provide the data of an entire hierarchy with a single request, and keeps references to related entities in memory to bypass the join computation at query time.

How does MonarchStore compare against a graph database?

Graph databases, such as Neo4J or OrientDB, store hard-links between entities and don't have to compute joins at query time. Yet, graph databases provide too much flexibility. In a graph database, any vertex can be linked to any other vertex of any type and vertices can be created even without a parent vertex to attach to. A hierarchical data store enforces every newly created entity to have a parent unless they are meant to be directly under the root.

Applications querying a graph database must construct a query string. These graph queries, in essence, redundantly redeclare the relationships among the entities in the hierarchy. There is a neglible but existent step for the graph databases to parse this query on every request. Entities in a hierarchical data store can only have one parent and zero or more children, and this information only needs to be provided at creation time.

How does MonarchStore compare against a key-value store?

Key-Value stores, such as Redis or Riak KV, provide the fastest reads when all data is stored as a JSON blob, but frequently modifying a deeply nested value is inneficient. The application must pull the entire hierarchy from the root to the leaves, deserialize it, make changes, serialize it, and update the data store. A hierarchical data store allows applications to efficiently create or update a single nested entity without reading all other entities in the hierarchy.

How does MonarchStore compare against a document store?

Document stores, such as MongoDB or Elasticsearch, need to make multiple round trips to get the child entities. The alternative is to store all the data into a single, large, highly-nested document, which is inneficient to fetch and update, and so large that it becomes too difficult to handle.

MonarchStore Features

Queries can return any entity in any of the hierarchy levels.
Queries can specify the depth level of child entities to reduce the amount of data returned.
Entities may have custom properties.
Each entity can be updated independently of it's parent or child entities.
In memory storage provides speedy reads and writes atomically.
The RESTful HTTP interface combines the application relational logic and the data store. When there is no additional domain logic to add, putting MonarchStore behind a protected proxy makes writing REST APIs unnecessary. Application architectures can be reduced from a database server + application server to a MonarchStore single server.

Setting up MonarchStore

Prerequisites

Go > 1.8

Compiling into a binary

go get github.com/MonarchStore/monarchs
cd $GOPATH/github.com/MonarchStore/monarchs
go install

Running the database

Environment

CLI Options

  -addr string
        The binding address (default ":6789")

REST API

Sample Usage

Below are sample REST CRUD actions for a registry of continents -> countries -> states -> cities. These actions are available as a Postman collection.

Define the "locations" hierarchy

POST http://localhost:6789/locations

["continents", "countries", "states", "cities"]

View the "locations" hiearchy we just created

GET http://localhost:6789/locations

Create a "continent" document under the "root" document

POST http://localhost:6789/locations/continents/north_america?parent=root

{"name": "North America"}

Create a "country" document

POST http://localhost:6789/locations/countries/usa?parent=north_america

{"name": "United States of America", "capital": "Washington, DC", "code": "usa"}

Create a "state" document

POST http://localhost:6789/locations/states/ny?parent=usa

{"name": "New York", "abbr": "NY"}

Create another "state" document

POST http://localhost:6789/locations/states/ca?parent=usa

{"name": "California", "abbr": "CA"}

Create a "city" document

POST http://localhost:6789/locations/cities/nyc?parent=ny

{"name": "New York City"}

Update a "city" document

PUT http://localhost:6789/locations/cities/nyc

{"name": "New York City", "stats": {"population_in_millions": 8.491}}

Read the "root" document and all the elements in the hierarchy

GET http://localhost:6789/locations/root/root?depth=4

The steps above would result in this hierarchy:

graph LR;
root:::current
    --> north_america[North America]:::child
    --> usa[United States of America]:::child
    --> ny[New York State]:::child
    --> nyc[New York City]:::child

usa
    --> ca[California]:::child

classDef current fill:#E3371E
classDef child fill:#0593A2
classDef parent fill:#103778

Read a "country" document, with all of its "state" documents and "city" documents

GET http://localhost:6789/locations/countries/usa?depth=2

Which would result in this hierarchy:

graph LR;
usa[United States of America]:::current
    --> ny[New York State]:::child
    --> nyc[New York City]:::child

usa
    --> ca[California]:::child

classDef current fill:#E3371E
classDef child fill:#0593A2
classDef parent fill:#103778

Read a "city" document, and the parent "state" document, and the grandparent "country" document

GET http://localhost:6789/locations/cities/nyc?depth=0&parents=2

Which would result in this hierarchy:

graph LR;
usa[United States of America]:::parent
    --> ny[New York State]:::parent
    --> nyc[New York City]:::current

classDef current fill:#E3371E
classDef child fill:#0593A2
classDef parent fill:#103778

Read a "country" document, the parent "continent" document, and the children "state" documents

GET http://localhost:6789/locations/countries/usa?depth=1&parents=1

Which would result in this hierarchy:

graph LR;
north_america[North America]:::parent
    --> usa[United States of America]:::current
    --> ny[New York State]:::child
usa
    --> ca[California]:::child

classDef current fill:#E3371E
classDef child fill:#0593A2
classDef parent fill:#103778

Delete a "country" document. All children "state" documents and grandchilden "city" documents are deleted as well

DELETE http://localhost:6789/locations/countries/usa

Delete the "locations" hierarchy

DELETE http://localhost:6789/locations
