shapely_filter

This tool filters a network consists of polylines, for example, a river network. Input and output are all MultiLineString. Source data like ESRI Shapefile and GeoJSON file can be filtered or simplified using this tool, however, the attribute table of the original data will not exist in your filtered data. The tool requires the Shapely Python package.

The tool does four things:

Remove short dead-end lines.
Remove short disjoint lines.
Remove rings.
Remove oxbow lakes.

Contributors

Yan Zhou yan.zhou@ufz.de

License & copyright

Acknowledegments

Thanks to the team of Hydroinformatics for improving the code and the discussions.

1. Remove short dead-end lines

Dead-end lines intersect only one other line. First, create a simple MultiLineString that needs to be filtered.

from shapely.geometry import MultiLineString
from pprint import pprint


# Original
multi_line = MultiLineString(
    [((-0.5, 1.5), (0.5, 1.5)), ((0.5, 1.5), (0.5, 2)), ((0.5, 1.5), (1.5, 1)), ((1.5, 1), (2, 0.5)),
     ((3, 1.5), (3, 2)), ((1.5, 1), (2, 1.5), (2.5, 1), (2, 0.5)), ((2, 0.5), (2, -0.5)),
     ((0, 0), (0, 1), (0.5, 0), (0, 0))])
pprint(list(multi_line))

Put shapely_filter.py in the project directory, here: 'C:\Jupyter', then import this python file from this directory. We need to insert the project file path too.

import sys
sys.path.insert(0, 'C:\Jupyter')

from shapely_filter import LineFilter

The original MultiLineString consists of 8 LineStrings. Three lines are dead-end lines: line ((-0.5, 1.5), (0.5, 1.5)), line ((0.5, 1.5), (0.5, 2)), and line ((2, 0.5), (2, -0.5)), which has a length of 1, 0.5, and 1, separately. Use remove_dead_end() method to filter out the short dead-end line ((0.5, 1.5), (0.5, 2)), which has a length shorter than 1. The remove_dead_end() method can be found in the class LineFilter within the shapey_filter.py module. The method returns a MultiLineString too. We first use update_length() method to define a length, lines shorter than this will be filtered out. The update_length() method defines length for remove_dead_end(), remove_disjoint(), and simplify_line() methods. The length should be adjusted based on the data or map you are working with, and use a projected map to work in meaningful units like meters.

my_multi_line = LineFilter(multi_line)
my_multi_line.update_length(1)

# Filtered
multi_line_filtered1 = my_multi_line.remove_dead_end()
print(type(multi_line_filtered1))

# Plot the original and the filtered network
%matplotlib inline
from matplotlib import pyplot
from figures import SIZE, set_limits, plot_line, plot_bounds, color_issimple
from figures import plot_coords as _plot_coords


def plot_coords(ax, ob):
    for line in ob:
        _plot_coords(ax, line, zorder=1)


def plot_lines(ax, ob):
    color = color_issimple(ob)
    for line in ob:
        plot_line(ax, line, color=color, alpha=0.7, zorder=2)


fig = pyplot.figure(1, figsize=SIZE, dpi=90)

# Original
ax = fig.add_subplot(121)

plot_coords(ax, multi_line)
plot_bounds(ax, multi_line)
plot_lines(ax, multi_line)

ax.set_title('a) original')
set_limits(ax, -1, 4, -1, 3)

# Filtered
ax = fig.add_subplot(122)

plot_coords(ax, multi_line_filtered1)
plot_bounds(ax, multi_line_filtered1)
plot_lines(ax, multi_line_filtered1)

ax.set_title('b) filtered')
set_limits(ax, -1, 4, -1, 3)

pyplot.show()

Note: the figures module simpily modifies the size of the Matplotlib figure, if you really need this module, it locates here: https://github.com/Toblerity/Shapely/blob/master/docs/code/figures.py, and you may put it in your project directory as well, here: 'C:\Jupyter'.

2. Remove short disjoint lines

Disjoint lines are lines that their boundary and interior do not intersect at all with those of the other.

my_multi_line = LineFilter(multi_line)
my_multi_line.update_length(1) # disjoint lines shorter than 1 will be filtered out

# Filtered
multi_line_filtered2 = my_multi_line.remove_disjoint()

# Plot the original and the filtered network
fig = pyplot.figure(1, figsize=SIZE, dpi=90)

# Original
ax = fig.add_subplot(121)

plot_coords(ax, multi_line)
plot_bounds(ax, multi_line)
plot_lines(ax, multi_line)

ax.set_title('a) original')
set_limits(ax, -1, 4, -1, 3)

# Filtered
ax = fig.add_subplot(122)

plot_coords(ax, multi_line_filtered2)
plot_bounds(ax, multi_line_filtered2)
plot_lines(ax, multi_line_filtered2)

ax.set_title('b) filtered')
set_limits(ax, -1, 4, -1, 3)

pyplot.show()

3. Remove rings

Self-contained rings share the same endpoint. Note that disjoint rings are also disjoint lines, thus will be removed already when using remove_disjoint() method, if their length are shorter than the given length.

my_multi_line = LineFilter(multi_line)

# Filtered
multi_line_filtered3 = my_multi_line.remove_ring()

# Plot the original and the filtered network
fig = pyplot.figure(1, figsize=SIZE, dpi=90)

# Original
ax = fig.add_subplot(121)

plot_coords(ax, multi_line)
plot_bounds(ax, multi_line)
plot_lines(ax, multi_line)

ax.set_title('a) original')
set_limits(ax, -1, 4, -1, 3)

# Filtered
ax = fig.add_subplot(122)

plot_coords(ax, multi_line_filtered3)
plot_bounds(ax, multi_line_filtered3)
plot_lines(ax, multi_line_filtered3)

ax.set_title('b) filtered')
set_limits(ax, -1, 4, -1, 3)

pyplot.show()

4. Remove oxbow lakes

Oxbow lake is U-shaped bend from a river or stream, which is cut off from the main stream and, in this case, still connected to the main stream at its both ends. All lines that share the same ends (start- and end point) will be compared with each other once, filter out longer lines and then return the shortest line. Oxbow lakes that connected at only one end or disconnected to the main stream are defined here as dead-end and disjoint lines, separately.

my_multi_line = LineFilter(multi_line)

# Filtered
multi_line_filtered4 = my_multi_line.remove_oxbow()

# Plot the original and the filtered network
fig = pyplot.figure(1, figsize=SIZE, dpi=90)

# Original
ax = fig.add_subplot(121)

plot_coords(ax, multi_line)
plot_bounds(ax, multi_line)
plot_lines(ax, multi_line)

ax.set_title('a) original')
set_limits(ax, -1, 4, -1, 3)

# Filtered
ax = fig.add_subplot(122)

plot_coords(ax, multi_line_filtered4)
plot_bounds(ax, multi_line_filtered4)
plot_lines(ax, multi_line_filtered4)

ax.set_title('b) filtered')
set_limits(ax, -1, 4, -1, 3)

pyplot.show()

5. Filtering using all methods

By default, the simplify_line() method will execute the above mentioned methods in this order: remove_dead_end(), remove_disjoint(), remove_ring(), and remove_oxbow(). However, remove_ring() or remove_oxbow() will not be executed if remove_ring=False or remove_oxbow=False. By default, they are True. Furthermore, by default, is_simplest=True, and if so, simplify_line() and remove_dead_end() methods will keep filtering out short dead-end lines from the previous result until there is no more short dead-end line left from your network, this is the simplest network you can get. If you don't want the simplest network, set is_simplest=False and define the level of simplification by assigning level=1, for example, if you only want to remove short dead-end lines once from your original network.

my_multi_line = LineFilter(multi_line)
my_multi_line.update_length(1)

# Filtered
multi_line_filtered = my_multi_line.simplify_line(remove_ring=True, remove_oxbow=True, is_simplest=True, level=None)

# Plot the original and the filtered network
fig = pyplot.figure(1, figsize=SIZE, dpi=90)

# Original
ax = fig.add_subplot(121)

plot_coords(ax, multi_line)
plot_bounds(ax, multi_line)
plot_lines(ax, multi_line)

ax.set_title('a) original')
set_limits(ax, -1, 4, -1, 3)

# Filtered
ax = fig.add_subplot(122)

plot_coords(ax, multi_line_filtered)
plot_bounds(ax, multi_line_filtered)
plot_lines(ax, multi_line_filtered)

ax.set_title('b) filtered')
set_limits(ax, -1, 4, -1, 3)

pyplot.show()

6. An application

Liechtenstein river and stream network (see folder Liechtenstein) is used here as an example to see how the tool works. The source data could be either a ESRI Shapefile or a GeoJSON file. The projected GeoJSON file consists of rivers and streams (line element) in Liechtenstein obtained from OpenStreetMap. Put the source file liechtenstein_river_stream_proj.geojson into your working directory. You should put the shapely_filter.py in your wokring directory too.

import fiona
import time
from shapely.geometry import shape, mapping, MultiLineString
from shapely.ops import unary_union, linemerge
from shapely_filter import LineFilter

# Read the source file with fiona and get the source driver, crs, and schema
with fiona.open("liechtenstein_river_stream_proj.geojson") as source:
    source_driver = source.driver
    source_crs = source.crs
    source_schema = source.schema

    # Returns a new, independent line geometry with coordinates
    multi_line = [shape(feature['geometry']) for feature in source]

    # Union LineStrings and MultiLineStrings into a MultiLineString (which also split lines at their intersections)
    multi_line_union = unary_union(multi_line)

    # Merge all contiguous lines, return a MultiLineString
    multi_line_merge = linemerge(multi_line_union)

    # Start recording the processing time
    start_time = time.time()

    # Using shapely_line_filter
    my_multi_line = LineFilter(multi_line_merge)

    # Define short (dead-end and disjoint) lines are those not longer than 1 km
    my_multi_line.update_length(1000)

    # Execute the filter
    multi_line_filtered = my_multi_line.simplify_line()
    print(f"Filtering lines lasted {round(time.time() - start_time, 0)} "
          f"seconds.")
    print(f"Number of lines before filtering: {len(multi_line_merge)}")
    print(f"Number of lines after filtering: {len(multi_line_filtered)}")

Filtering lines lasted 4.0 seconds.
Number of lines before filtering: 402
Number of lines after filtering: 62

# Plot the original and the filtered network
from math import sqrt


def plot_lines(ax, ob):
    color = color_issimple(ob)
    for line in ob:
        plot_line(ax, line, color=color, linewidth=1, alpha=0.7, zorder=2)

GM = (sqrt(5)-1.0)/2.0
W = 8.0
H = W/GM
SIZE = (W, H)

fig = pyplot.figure(1, figsize=(SIZE), dpi=90)

# Original
ax = fig.add_subplot(121)
plot_lines(ax, multi_line_merge)
ax.set_title('a) original')
ax.set_xlim(533200, 549200)
ax.set_xticks(range(533200, 549200+1, 4000))
ax.set_ylim(5207200, 5231200)
ax.set_yticks(range(5207200, 5231200+1, 4000))
ax.set_aspect("equal")

# Filtered
ax = fig.add_subplot(122)
plot_lines(ax, multi_line_filtered)
ax.set_title('b) filtered')
ax.set_xlim(533200, 549200)
ax.set_xticks(range(533200, 549200+1, 4000))
ax.set_ylim(5207200, 5231200)
ax.set_yticks(range(5207200, 5231200+1, 4000))
ax.set_aspect("equal")

pyplot.show()

# Write shapely geometries to shapefiles in your working directory
with fiona.open('201028_river4ogs_Liechtenstein_river_stream_v1.shp', 'w',
                driver='ESRI Shapefile',
                crs=source_crs,
                schema=source_schema) as c:
    for line in multi_line_filtered:
        c.write(dict(geometry=mapping(line),
                     properties=source_schema['properties']))
