PaintCodeKit manage your converted images in PaintCode. You will be able to use your images directly in the views using extensions with correct sizes. Use it to maintain your code clean!

Import your code from PaintCodeKit
Customizable images
Clean code!
Easy usage
Supports iOS, developed in Swift 5

Installation

PaintCodeKit is available through CocoaPods. To install it, simply add the following line to your Podfile and run pod install:

Then you can import it when you need

Usage

In the example you can see how to include you own images in UIImageViews and how to create an UIImage with PaintCodeManager. Once you've installed the pod, follow next steps. It's really simple:

Fill your UIImageView

Use PaintCodeImage enum to fill with images preloaded in this pod.

// This will get imageView frame to get default image size
imageView.draw(PaintCodeImage.user)

// Extended mode
imageView.draw(PaintCodeImage.user, size: CGSize(width: 10, height: 10), color: .white, cached: true)

In other case, make your own enum type with PaintCodeDraw protocol implementing draw method. Follow next example:

enum Icon: PaintCodeDraw {

    case shareApp
    case bell

    func draw(size: CGSize, color: UIColor) {
        switch self {
        case .shareApp: PaintCodeImages.drawShareApp(frame: CGRect(origin: .zero, size: size), resizing: .aspectFit)
        case .bell: PaintCodeImages.drawBell(frame: CGRect(origin: .zero, size: size), resizing: .aspectFit)
        }
    }
}

As you can see above, draw method, will draw your custom image from PaintCode code. So you must extend PaintCodeImages and paste PaintCode code generated draw methods:

extension PaintCodeImages {

    class func drawShareApp(frame targetFrame: CGRect = CGRect(x: 0, y: 0, width: 400, height: 400), resizing: ResizingBehavior = .aspectFit) {

        /// General Declarations
        let context = UIGraphicsGetCurrentContext()!

        /// Resize to Target Frame
        context.saveGState()
        let resizedFrame = resizing.apply(rect: CGRect(x: 0, y: 0, width: 24, height: 24), target: targetFrame)
        context.translateBy(x: resizedFrame.minX, y: resizedFrame.minY)
        context.scaleBy(x: resizedFrame.width / 24, y: resizedFrame.height / 24)

        /// Combined Shape
        let combinedShape = UIBezierPath()
        combinedShape.move(to: CGPoint(x: 10, y: 3.41))
        combinedShape.addLine(to: CGPoint(x: 10, y: 14))
        combinedShape.addCurve(to: CGPoint(x: 9, y: 15), controlPoint1: CGPoint(x: 10, y: 14.55), controlPoint2: CGPoint(x: 9.55, y: 15))
        combinedShape.addCurve(to: CGPoint(x: 8, y: 14), controlPoint1: CGPoint(x: 8.45, y: 15), controlPoint2: CGPoint(x: 8, y: 14.55))
        combinedShape.addLine(to: CGPoint(x: 8, y: 3.41))
        [...]

        context.restoreGState()
    }
}

Generate a UIImage

Simple ;)

let image = PaintCodeManager.image(PaintCodeImage.user)

Defaults

You can change some default values in PaintCodeManager:

/// Image size
PaintCodeManager.shared.defaultSize = CGSize(width: 30, height: 30)

/// Default image color
PaintCodeManager.shared.defaultColor = UIColor.black

/// Cache generated images
PaintCodeManager.shared.defaultCached = true

Extra

Also you can make use of anyone of the included images in PaintCodeKit.

/// Example
PaintCodeImage.user

PaintCodeImage	Preview
`.user`

Author

Alberto Aznar, info@alberdev.com

Contributing

Fork it!
Create your feature branch: git checkout -b my-new-feature
Commit your changes: git commit -am 'Add some feature'
Push to the branch: git push origin my-new-feature
Submit a pull request :D

License

PaintCodeKit is available under the MIT license. See the LICENSE file for more info.
