The original neural network from Torch7, nn, contains stable and widely used modules. 'nnx' contains more experimental, unproven modules, and optimizations. Modules that become stable and which are proven useful make their way into 'nn' (some already have).

The forward method returns an output Tensor of size 1D, while backward returns a table {gradInput, gradTarget}. The second variable is just a Tensor of zeros , such that the targets can be propagated through Containers like ParallelTable.

> input = torch.randn(5,10)
> target = torch.IntTensor{20,24,27,10,12}
> gradOutput = torch.randn(5)
> root_id = 29
> input_size = 10
> hierarchy = {
>>    [29]=torch.IntTensor{30,1,2}, [1]=torch.IntTensor{3,4,5},
>>    [2]=torch.IntTensor{6,7,8}, [3]=torch.IntTensor{9,10,11},
>>    [4]=torch.IntTensor{12,13,14}, [5]=torch.IntTensor{15,16,17},
>>    [6]=torch.IntTensor{18,19,20}, [7]=torch.IntTensor{21,22,23},
>>    [8]=torch.IntTensor{24,25,26,27,28}
>> }
> smt = nn.SoftMaxTree(input_size, hierarchy, root_id)
> smt:forward{input, target}
-3.5186
-3.8950
-3.7433
-3.3071
-3.0522
[torch.DoubleTensor of dimension 5]
> smt:backward({input, target}, gradOutput)
{
  1 : DoubleTensor - size: 5x10
  2 : IntTensor - size: 5
}

An example utilizing the above SoftMaxTree Module and a Linear Module demonstrates how the PushTable can be used to forward the target Tensor without any other Table Modules:

> mlp = nn.Sequential()
> linear = nn.Linear(50,100)
> push = nn.PushTable(2)
> pull = push:pull(2)
> mlp:add(push)
> mlp:add(nn.SelectTable(1))
> mlp:add(linear)
> mlp:add(pull)
> mlp:add(smt) --smt is a SoftMaxTree instance
> mlp:forward{input, target} -- input and target are defined above
-3.5186
-3.8950
-3.7433
-3.3071
-3.0522
[torch.DoubleTensor of dimension 5]
> mlp:backward({input, target}, gradOutput) -- so is gradOutput
{
  1 : DoubleTensor - size: 5x10
  2 : IntTensor - size: 5
}

> mlp2 = nn.Sequential()
> para = nn.ParallelTable()
> para:add(linear)
> para:add(nn.Identity())
> mlp2:add(para)
> mlp2:add(smt)
> mlp2:forward{input, target}
-3.5186
-3.8950
-3.7433
-3.3071
-3.0522
[torch.DoubleTensor of dimension 5]
> mlp2:backward({input, target}, gradOutput)
{
  1 : DoubleTensor - size: 5x10
  2 : IntTensor - size: 5
}

In some cases, this can simplify the digraph of Modules. Note that a PushTable can be associated to many PullTables, but each PullTable is associated to only one PushTable.

### CTCCriterion ### ``` criterion = nn.CTCCriterion() ``` Creates a Criterion based on Baidus' [warp-ctc](https://github.com/baidu-research/warp-ctc) implementation. This Module measures the loss between a 3D output of (batch x time x inputdim) and a target without needing alignment of inputs and labels. Must have installed warp-ctc which can be installed via luarocks: ``` luarocks install http://raw.githubusercontent.com/baidu-research/warp-ctc/master/torch_binding/rocks/warp-ctc-scm-1.rockspec ``` Supports cuda via: ``` criterion = nn.CTCCriterion():cuda() ``` Example: ``` output = torch.Tensor({{{1,2,3,4,5},{6,7,8,9,10}}}) -- Tensor of size 1x1x5 (batch x time x inputdim). label = {{1,3}} sizes = torch.Tensor({2}) -- Size of each sequence (sequence-length) in the batch as a tensor ctcCriterion = nn.CTCCriterion()

err = ctcCriterion:forward(output,label,sizes) gradOut = ctcCriterion:backward(output,label) print("----CPU----") print("Error : " .. err) print("Gradients :") print(gradOut)

ctcCriterion = ctcCriterion:cuda() -- Switch to cuda implementation. output = output:cuda()

err = ctcCriterion:forward(output,label,sizes) gradOut = ctcCriterion:backward(output,label) print("----GPU----") print("Error : " .. err) print("Gradients :") print(gradOut)

----CPU---- Error : 4.9038286209106 Gradients : (1,.,.) = 0.0117 -0.9683 0.0861 0.2341 0.6364 0.0117 0.0317 0.0861 -0.7659 0.6364 [torch.FloatTensor of size 1x2x5]

----GPU---- Error : 4.9038290977478 Gradients : (1,.,.) = 0.0117 -0.9683 0.0861 0.2341 0.6364 0.0117 0.0317 0.0861 -0.7659 0.6364 [torch.CudaTensor of size 1x2x5]

<a name='nnx.MultiSoftMax'/>
### MultiSoftMax ###
This Module takes 2D or 3D input and performs a softmax over the last dimension.
It uses the existing [SoftMax](https://github.com/torch/nn/blob/master/doc/transfer.md#nn.SoftMax)
CUDA/C code to do so such that the Module can be used on both GPU and CPU.
This can be useful for [keypoint detection](https://github.com/nicholas-leonard/dp/blob/master/doc/facialkeypointstutorial.md#multisoftmax).

<a name='nnx.SpatialReSampling'/>
### SpatialReSampling ###
Applies a 2D re-sampling over an input image composed of
several input planes (or channels, colors). The input tensor in `forward(input)` is
expected to be a 3D or 4D tensor of size : `[batchSize x] nInputPlane x width x height`.
The number of output planes will be the same as the number of input
planes.

The re-sampling is done using [bilinear interpolation](http://en.wikipedia.org/wiki/Bilinear_interpolation).
For a simple nearest-neihbor upsampling, use `nn.SpatialUpSampling()`,
and for a simple average-based down-sampling, use
`nn.SpatialDownSampling()`.

If the input image is a 3D tensor of size `nInputPlane x height x width`,
the output image size will be `nInputPlane x oheight x owidth` where
`owidth` and `oheight` are given to the constructor.

Instead of `owidth` and `oheight`, one can provide `rwidth` and `rheight`,
such that `owidth = iwidth*rwidth` and `oheight = iheight*rheight`.

As an example, we can run the following code on the famous Lenna image:
```lua
require 'image'
require 'nnx'
input = image.loadPNG('doc/image/Lenna.png')
l = nn.SpatialReSampling{owidth=150,oheight=150}
output = l:forward(input)
image.save('doc/image/Lenna-150x150-bilinear.png', output)

The input:

Lenna

The re-sampled output:

Lenna re-sampled

Once loaded, tab-completion will help you navigate through the library (note that most function are added directly to nn):

> nnx. + TAB
...
> nn. + TAB

> nnx.test_all()
> nnx.test_omp()
