A modern Electron application template with React, Vite, TypeScript, and TailwindCSS. This project provides a solid foundation for developing cross-platform desktop applications.

Watch Video Preview

Stack

🔹 Electron - Cross-platform desktop application framework.
🔹 React - The library for web and native user interfaces.
🔹 TypeScript - Type-safe JavaScript.
🔹 Shadcn UI - Beautiful and accessible component library.
🔹 TailwindCSS - Utility-first CSS framework.
🔹 Electron Vite - Lightning-fast build tool based on Vite for fastest hot-reload.
🔹 Electron Builder - Configured for packaging applications.

In-Built Features

Installation

Clone the repository:

# Clone the repository
git clone https://github.com/guasam/electron-react-app

# Change directory
cd electron-react-app

# Install dependencies (use any package manager: npm, yarn, pnpm, bun)
npm install

Development

Start the development server:

This will start Electron with hot-reload enabled so you can see changes in real time.

Conveyor - Inter-Process Communication

Conveyor is a type-safe IPC system that enables secure communication between your React frontend and Electron's main process. It uses Zod schemas for runtime validation and provides full TypeScript support.

🔹 Type-safe - Full TypeScript support with compile-time and runtime validation
🔹 Secure - Validates all data using Zod schemas
🔹 Modular - Clean API structure with organized handlers
🔹 Simple - Easy-to-use React hooks and global APIs

Quick Start

Use the useConveyor hook in your React components:

import { useConveyor } from '@/app/hooks/use-conveyor'

function MyComponent() {
  const { version } = useConveyor('app')
  const { windowMinimize } = useConveyor('window')

  const handleGetVersion = async () => {
    console.log('App version:', await version())
    console.log('App version:', await window.conveyor.app.version()) // OR
  }

  return (
    <div>
      <button onClick={handleGetVersion}>Get Version</button>
      <button onClick={windowMinimize}>Minimize Window</button>
    </div>
  )
}

Available APIs

Conveyor provides two ways to access IPC methods:

// Method 1: React Hook (Recommended)
const { version } = useConveyor('app')
await version()

// Method 2: React Hook Global Conveyor
const conveyor = useConveyor()
await conveyor.app.version()

// Method 3: Global Window Object
await window.conveyor.app.version()

Built-in APIs

Creating Custom APIs

Follow these 4 simple steps to add your own IPC methods:

Step 1: Define Schema

Create a schema in lib/conveyor/schemas/app-schema.ts:

import { z } from 'zod'

export const appIpcSchema = {
  // Simple method with no parameters
  'get-app-info': {
    args: z.tuple([]),
    return: z.object({
      name: z.string(),
      version: z.string(),
      platform: z.string(),
    }),
  },

  // Method with parameters
  'save-user-preference': {
    args: z.tuple([
      z.object({
        key: z.string(),
        value: z.string(),
      }),
    ]),
    return: z.boolean(),
  },
} as const

Step 2: Add API Method

Update lib/conveyor/api/app-api.ts:

export class AppApi extends ConveyorApi {
  getAppInfo = () => this.invoke('get-app-info')
  saveUserPreference = (key: string, value: string) => this.invoke('save-user-preference', { key, value })
}

Step 3: Implement Handler

Add handler in lib/conveyor/handlers/app-handler.ts:

import { handle } from '@/lib/main/shared'
import { app } from 'electron'

export const registerAppHandlers = () => {
  handle('get-app-info', () => ({
    name: app.getName(),
    version: app.getVersion(),
    platform: process.platform,
  }))

  handle('save-user-preference', async ({ key, value }) => {
    // Save to file, database, etc.
    console.log(`Saving ${key}: ${value}`)
    return true
  })
}

Step 4: Register Handler

In lib/main/app.ts:

import { registerAppHandlers } from '@/lib/conveyor/handlers/app-handler'

// During app initialization
registerAppHandlers()

Usage in Components

function SettingsComponent() {
  const conveyor = useConveyor()
  const [appInfo, setAppInfo] = useState(null)

  useEffect(() => {
    // Get app information
    conveyor.app.getAppInfo().then(setAppInfo)
  }, [])

  const saveTheme = (theme: string) => {
    conveyor.app.saveUserPreference('theme', theme)
  }

  return (
    <div>
      <h2>App Info</h2>
      {appInfo && (
        <p>
          {appInfo.name} v{appInfo.version} on {appInfo.platform}
        </p>
      )}

      <button onClick={() => saveTheme('dark')}>Set Dark Theme</button>
    </div>
  )
}

Error Handling

const handleApiCall = async () => {
  try {
    const result = await conveyor.app.getAppInfo()
    console.log('Success:', result)
  } catch (error) {
    console.error('API call failed:', error)
    // Handle validation errors, network issues, etc.
  }
}

Type Safety Benefits

// ✅ TypeScript enforces correct types
const info = await conveyor.app.getAppInfo() // Returns { name: string, version: string, platform: string }

// ❌ TypeScript error - wrong parameter type
const result = await conveyor.app.saveUserPreference(123, 'value') // Error: Expected string, got number

// ✅ Runtime validation ensures data integrity
const valid = await conveyor.app.saveUserPreference('theme', 'dark') // Validates at runtime

📖 For advanced usage and detailed documentation, see Conveyor README

Custom Window Components

This template includes a custom window implementation with:

• Custom titlebar with app icon
• Window control buttons (minimize, maximize, close)
• Menu system with keyboard shortcuts
• Dark/light mode toggle
• Cross-platform support for Windows and macOS

Titlebar Menu Toggle

The titlebar menu can be toggled using:

• Windows: Press the Alt key
• macOS: Press the Option (⌥) key

When you press the toggle key:

• If the menu is hidden, it becomes visible
• If the menu is already visible, it gets hidden
• The menu only toggles if menu items are available

Customizing Menu Items

To add, remove or modify menu items, update the following file:

• app/components/window/menus.ts

Tailwind CSS

The project supports Tailwind for styling:

// Example component with Tailwind classes
const Button = () => (
  <button className="px-4 py-2 text-white rounded-md">
    Click me
  </button>
);

Key Directories Explained

app/ - Renderer Process

• React application that runs in the browser window
• Contains all UI components, styles, and client-side logic
• Uses Vite for fast development and building

lib/conveyor/ - Conveyor - Inter-Process Communication

• Type-safe communication between renderer and main processes
• API classes provide clean interfaces for IPC calls
• Handlers implement the actual logic in the main process
• Schemas define data contracts with Zod validation

lib/main/ - Main Process

• Electron main process code
• Handles window creation, app lifecycle, and system integration
• Registers IPC handlers and manages app state

lib/preload/ - Preload Scripts

• Security bridge between renderer and main processes
• Exposes safe APIs to the renderer process
• Implements context isolation for security

Development Workflow

1. UI Development: Work in app/ directory with React components
2. IPC Communication: Define schemas, add API methods, implement handlers
3. Window Features: Customize window behavior in app/components/window/
4. Prettier Formatting: Use npm run format to format the code.
5. ESLint: Use npm run lint to lint the code.

Path Aliases

The project uses TypeScript path aliases for clean imports:

// Instead of relative paths like:
import { Button } from '../../../components/ui/button'

// Use clean aliases:
import { Button } from '@/app/components/ui/button'
import { conveyor } from '@/lib/conveyor/api'

Configured aliases by default, customise as you want:

• @/ → app/ (application code - renderer process)
• @/lib/ → lib/ (shared library code containing conveyor, main, preload, etc.)
• @/resources/ → resources/ (build resources for the application)

Building for Production

Build the application for your platform:

# For Windows
npm run build:win

# For macOS
npm run build:mac

# For Linux
npm run build:linux

# Unpacked for all platforms
npm run build:unpack

Distribution files will be located in the dist directory.
