Binary database using AVL tree data structure (Balanced-Binary Tree)

An implementation of the AVL tree to store data. I'm also include basic transaction handling with commit and rollback methods using in-memory snapshots and saving it to a .pkl (binary file)

The Only necessary file

databasestructure.py

How to Use

Note: see an example with main.py file

Import databasestructure

import pickle
from databasestructure import *

Create a database object

Create a table

Example about how to create a table named users, with columns id, name and age:

db.create_table('users', ['id', 'name', 'age'], key_index=0)

Note: key_index is wich column index has the id column, in this case id is on the first column, that's why key_index = 0.

Insert data to table

db.insert('users', [None, 'Alice', 30])
db.commit('users')

Note: The id column is the index, you use None to use the automatic autoincrement feature

Select (search) Data

Select data based on the index

This will look on the id column.

# Select the user with id=0
headers, user = db.select('users', 0)
print(headers)
print(user)

Select data based on a value of a column

# Select the user with age > 25
headers, user = db.select_by_column_value("users", "age", '>', 25)
print(headers)
print(user)

Valid operators:

• >
• >=
• <
• <=
• ==
• !=

Select data whole table

# Select table
headers, table = db.select_all('users')
print(headers)
print(table)

Update Data

Update a row

# You need the index of the row to be updated
user = db.update('users', 0, [0, 'Alice', 31])
print(user)

Update a Table

# Add the column email to users table
db.add_column('users', 'email')
print(db.select_all('users'))

Delete Data

# You need the index of the row to be deleted
db.delete('users', 1)

Joining Operation

Let's say that we have these tables:

• Table users:

• Table orders:

If we want to join tables, we must do it based on the key_index value.

So, to join table users and table orders by user_id column:

# Perform the join
headers, joined_data = db.join('users', 'orders', key_index1=0, key_index2=1)

# Print the joined data
print("Joined Data:\n")
print(headers)
for data in joined_data:
    print(data)

• key_index1 = 0: This means that the join key for the first table (users) is in the first column (id).
• key_index2 = 1: This means that the join key for the second table (orders) is in the second column (user_id).

Note: Check test_joining.py file

• Result will be:

Transactions

Rollback

db.insert('users', [None, 'Charlie', 28])
print("Before rollback user with latest id:", db.select_all('users'))
db.rollback('users')
print("After rollback user with latest:", db.select_all('users'))

Commit

db.insert('users', [None, 'Charlie', 28])
db.commit('users')
print("After commit user with latest id:", db.select_all('users'))

Save data to a .pkl file

# Save the database in binary format
db.save('./avl_database.pkl')

Load data from a .pkl file

# Load the database in binary format
db = CustomDatabase.load('./avl_database.pkl')

Load data from a .csv file

You must have a .csv with the same structure that the table you want to upload. Let's say table users, you will need a .csv file with a structure like the example:

db.load_from_csv("users", "./data.csv")

Added Multi-threading operations

Please check: main_multi_threading.py file

Test

Inside of the dummy_data folder, there a generator of dummy data and main_test.py that will execute basic operations to test the database performance:

The results may vary due to CPU capabilities, and if you want to use multi-thread. For test support i used only 1 thread and a 11th Gen Intel(R) Core(TM) i3-1115G4 @ 3.00GHz CPU (very normal CPU).

Used 10,000 dummy users and 20,000 orders.
