graph TB
    User([User]) --> UI[Chat Interface]
    UI --> ChatStore[Chat Store]
    UI --> DocStore[Document Store]
    UI --> ModelStore[Model Store]

    subgraph "Frontend Layer"
        UI
        ChatStore
        DocStore
        ModelStore
        ThemeStore[Theme Store]
    end

    subgraph "Service Layer"
        ModelManager[Model Manager]
        RAGService[RAG Service]
        EmbeddingService[Embedding Service]
        VectorStore[Vector Store]
        DocProcessor[Document Processor]
    end

    subgraph "WebLLM Engine"
        WebLLMCore[WebLLM Core]
        WebGPU[WebGPU Runtime]
        ModelCache[Model Cache]
    end

    subgraph "Storage Layer"
        IndexedDB[(IndexedDB)]
        LocalStorage[(Local Storage)]
        BrowserCache[(Browser Cache)]
    end

    subgraph "Document Processing"
        PDFParser[PDF.js Parser]
        DOCXParser[Mammoth.js Parser]
        TextParser[Text Parser]
        MDParser[Markdown Parser]
    end

    ChatStore --> ModelManager
    DocStore --> RAGService
    ModelStore --> ModelManager

    ModelManager --> WebLLMCore
    RAGService --> EmbeddingService
    RAGService --> VectorStore
    RAGService --> DocProcessor

    DocProcessor --> PDFParser
    DocProcessor --> DOCXParser
    DocProcessor --> TextParser
    DocProcessor --> MDParser

    WebLLMCore --> WebGPU
    WebLLMCore --> ModelCache

    ModelManager --> IndexedDB
    VectorStore --> IndexedDB
    RAGService --> IndexedDB
    ChatStore --> LocalStorage
    ThemeStore --> LocalStorage
    ModelCache --> BrowserCache

    style User fill:#e1f5fe
    style WebGPU fill:#fff3e0
    style IndexedDB fill:#f3e5f5
    style LocalStorage fill:#f3e5f5
    style BrowserCache fill:#f3e5f5

classDiagram
    class ChatInterface {
        -messages: ChatMessage[]
        -inputText: string
        -isLoading: boolean
        +sendMessage(text: string): void
        +clearChat(): void
        +handleFileUpload(files: File[]): void
    }

    class ModelManager {
        -currentModel: string
        -availableModels: ModelInfo[]
        -loadingProgress: number
        +loadModel(modelId: string): Promise~void~
        +switchModel(modelId: string): void
        +getModelInfo(): ModelInfo
    }

    class RAGService {
        -vectorStore: VectorStore
        -embeddingService: EmbeddingService
        +addDocument(doc: Document): Promise~void~
        +search(query: string): Promise~SearchResult[]~
        +updateSettings(settings: RAGSettings): void
    }

    class VectorStore {
        -embeddings: Map~string, Vector~
        -documents: Map~string, DocumentChunk~
        +addEmbedding(id: string, vector: Vector): void
        +findSimilar(query: Vector, k: number): SearchResult[]
        +clear(): void
    }

    class EmbeddingService {
        -model: EmbeddingModel
        +generateEmbedding(text: string): Promise~Vector~
        +batchEmbed(texts: string[]): Promise~Vector[]~
    }

    class DocumentProcessor {
        +processFile(file: File): Promise~ProcessedDocument~
        +extractText(buffer: ArrayBuffer, type: string): Promise~string~
        +chunkDocument(text: string, options: ChunkOptions): DocumentChunk[]
    }

    class WebLLMCore {
        -engine: MLCEngine
        -config: EngineConfig
        +initializeEngine(): Promise~void~
        +chat(messages: Message[]): Promise~string~
        +streamChat(messages: Message[]): AsyncGenerator~string~
    }

    class ChatStore {
        -sessions: ChatSession[]
        -currentSession: ChatSession
        +addMessage(message: ChatMessage): void
        +createSession(): ChatSession
        +loadSession(id: string): void
        +saveToLocalStorage(): void
    }

    class DocumentStore {
        -documents: Document[]
        -chunks: DocumentChunk[]
        +addDocument(doc: Document): void
        +removeDocument(id: string): void
        +getChunksByDocument(docId: string): DocumentChunk[]
    }

    class ThemeStore {
        -currentTheme: string
        -availableThemes: Theme[]
        +setTheme(theme: string): void
        +getTheme(): Theme
    }

    ChatInterface --> ChatStore : uses
    ChatInterface --> ModelManager : uses
    ChatInterface --> RAGService : uses
    ChatInterface --> DocumentProcessor : uses file upload

    ModelManager --> WebLLMCore : manages

    RAGService --> VectorStore : stores vectors
    RAGService --> EmbeddingService : generates embeddings
    RAGService --> DocumentStore : retrieves documents

    DocumentProcessor --> DocumentStore : stores processed docs

    ChatStore --> WebLLMCore : sends messages

    VectorStore --> IndexedDB : persists data
    DocumentStore --> IndexedDB : persists data
    ChatStore --> LocalStorage : persists sessions
    ThemeStore --> LocalStorage : persists theme

    class IndexedDB {
        <<external>>
        +put(store: string, data: any): Promise~void~
        +get(store: string, key: string): Promise~any~
        +delete(store: string, key: string): Promise~void~
    }

    class LocalStorage {
        <<external>>
        +setItem(key: string, value: string): void
        +getItem(key: string): string
        +removeItem(key: string): void
    }

sequenceDiagram
    participant User
    participant ChatInterface
    participant ChatStore
    participant ModelManager
    participant WebLLMCore
    participant WebGPU
    participant BrowserCache

    User->>ChatInterface: Types message and sends
    ChatInterface->>ChatStore: addMessage(userMessage)
    ChatStore->>ChatStore: Save to LocalStorage
    ChatInterface->>ModelManager: checkModelLoaded()

    alt Model not loaded
        ModelManager->>WebLLMCore: initializeEngine()
        WebLLMCore->>BrowserCache: Check for cached model
        alt Model cached
            BrowserCache-->>WebLLMCore: Return cached model
        else Model not cached
            WebLLMCore->>WebLLMCore: Download model from CDN
            WebLLMCore->>BrowserCache: Cache model
        end
        WebLLMCore->>WebGPU: Load model to GPU
        WebGPU-->>WebLLMCore: Model ready
        WebLLMCore-->>ModelManager: Engine initialized
    end

    ChatInterface->>ChatStore: getConversationHistory()
    ChatStore-->>ChatInterface: Return messages[]
    ChatInterface->>ModelManager: generateResponse(messages)
    ModelManager->>WebLLMCore: streamChat(messages)
    WebLLMCore->>WebGPU: Process tokens

    loop Streaming response
        WebGPU-->>WebLLMCore: Generated tokens
        WebLLMCore-->>ModelManager: Token stream
        ModelManager-->>ChatInterface: Update response
        ChatInterface->>ChatInterface: Display streaming text
    end

    ChatInterface->>ChatStore: addMessage(aiResponse)
    ChatStore->>ChatStore: Save to LocalStorage
    ChatInterface-->>User: Display complete response

sequenceDiagram
    participant User
    participant ChatInterface
    participant DocumentProcessor
    participant RAGService
    participant EmbeddingService
    participant VectorStore
    participant DocumentStore
    participant IndexedDB

    Note over User,ChatInterface: Document Upload Flow
    User->>ChatInterface: Uploads document
    ChatInterface->>DocumentProcessor: processFile(file)

    alt PDF Document
        DocumentProcessor->>DocumentProcessor: PDF.js extraction
    else DOCX Document
        DocumentProcessor->>DocumentProcessor: Mammoth.js conversion
    else Text/Markdown
        DocumentProcessor->>DocumentProcessor: Direct text processing
    end

    DocumentProcessor->>DocumentProcessor: chunkDocument(text, options)
    DocumentProcessor->>DocumentStore: addDocument(processedDoc)
    DocumentStore->>IndexedDB: persistDocument()

    DocumentProcessor->>RAGService: indexDocument(chunks)

    loop For each chunk
        RAGService->>EmbeddingService: generateEmbedding(chunkText)
        EmbeddingService->>EmbeddingService: TF-IDF calculation
        EmbeddingService-->>RAGService: Return vector
        RAGService->>VectorStore: addEmbedding(chunkId, vector)
    end

    VectorStore->>IndexedDB: persistEmbeddings()
    RAGService-->>ChatInterface: Document indexed
    ChatInterface-->>User: Show upload success

    Note over User,ChatInterface: Query with RAG Flow
    User->>ChatInterface: Sends question
    ChatInterface->>RAGService: search(userQuery)
    RAGService->>EmbeddingService: generateEmbedding(query)
    EmbeddingService-->>RAGService: Query vector

    RAGService->>VectorStore: findSimilar(queryVector, k)
    VectorStore->>VectorStore: Calculate cosine similarity
    VectorStore-->>RAGService: Top k chunks

    RAGService->>DocumentStore: getChunkDetails(chunkIds)
    DocumentStore->>IndexedDB: fetchChunks()
    IndexedDB-->>DocumentStore: Chunk data
    DocumentStore-->>RAGService: Enriched chunks

    RAGService->>RAGService: Format context
    RAGService-->>ChatInterface: SearchResults + Context

    ChatInterface->>ChatInterface: Augment prompt with context
    ChatInterface->>ModelManager: generateResponse(augmentedPrompt)
    Note right of ModelManager: Continue with LLM flow

    ChatInterface-->>User: Display response with sources
