GitHub - scalytics/kshark-core: Command-line network sniffer for Kafka. Tests DNS, TCP, TLS, SASL, protocol, produce/consume in one tool. Built for SREs and AI agents (structured JSON output).

A powerful command-line diagnostic tool for Apache Kafka and connector target connectivity

kshark acts like a network sniffer for Kafka, providing comprehensive health checks of your entire agent-to-broker communication path — and now also validates connectivity from Kafka Connect workers to their source and sink database targets (MongoDB, PostgreSQL, DB2). It systematically tests every layer from DNS resolution through TLS security to application protocol-level interactions, helping developers and SREs quickly identify and resolve connectivity issues.

Built for AI Agents and Teams of Collaborating Experts

Tools are the difference between AI assistants and AI operators.

Without reliable, structured tools, AI agents are limited to conversation. With them, they become autonomous operators capable of real diagnostic work. kshark is designed from the ground up to be agent-executable:

Deterministic Output: Structured JSON and HTML reports that agents can parse, analyze, and act upon
Layered Diagnostics: Clear failure isolation (L3→L4→L5-6→L7) so agents know exactly where problems occur
Zero Human Intervention: Fully automated execution with -y flag, timeout controls, and exit codes
Rich Context: Every test returns actionable data — not just pass/fail, but metrics, timestamps, and error details

Why This Matters:

Human operators diagnose Kafka issues by running multiple commands: nslookup, telnet, openssl s_client, kafka-console-producer. They correlate failures, infer root causes, and retry with different parameters.

AI agents need to do the same work — but they need tools that package that workflow into a single, reliable interface. kshark is that interface for Kafka connectivity validation.

When an agent needs to validate a client configuration, diagnose a connection failure, or verify topic accessibility, kshark provides the structured, comprehensive output required to make informed decisions and take corrective action.

This is the future of infrastructure operations: agents equipped with purpose-built diagnostic tools, operating autonomously to validate, diagnose, and remediate connectivity issues before they impact production.

Made with ❤️ for the Kafka community

Key Features

Comprehensive Connectivity Testing

Layered Diagnostics: Systematically tests all layers of connectivity:
- L3 (Network): DNS resolution and latency
- L4 (Transport): TCP connection establishment
- L5-6 (Security): TLS handshake, certificate validation, and expiry monitoring
- L7 (Application): Kafka protocol, metadata retrieval, topic visibility
- L7 (HTTP): Schema Registry and REST Proxy connectivity
- L7 (Connector Targets): MongoDB, PostgreSQL, DB2 connectivity via Kafka Connect config
- Diagnostics: Traceroute, MTU discovery, PMTU black hole detection
- Neighborhood Scan: Port-level and protocol-level restriction detection
End-to-End Testing: Full produce-and-consume loop validation to verify complete data flow
Network Restriction Detection: When TCP fails, automatically scans nearby ports (80, 443, 9092-9094) and compares ICMP vs TCP reachability to classify firewall/NSG restrictions
Diagnostics Bundle: Package reports, logs, redacted Terraform state, and system context into a portable .tar.gz with ready-to-use export commands (scp, docker cp, kubectl cp)
Multiple Authentication Methods:
- SASL/PLAIN
- SASL/SCRAM-SHA-256
- SASL/SCRAM-SHA-512
- Mutual TLS (mTLS)
- SASL/GSSAPI (Kerberos) - with build tag

AI-Powered Analysis (Premium)

Intelligent Root Cause Detection: Identifies which layer is causing issues
Actionable Recommendations: Provides specific fix suggestions
Multiple AI Providers: Supports OpenAI, Scalytics-Connect, and custom endpoints
Automatic Problem Prioritization: Focuses on critical failures first

Developer-Friendly

Familiar Configuration: Java properties file format (works with existing Kafka configs)
Rich Output Formats:
- Color-coded console output
- Detailed HTML reports with visual summaries
- Machine-readable JSON export (Premium)
Quick Presets: Pre-configured templates for common Kafka distributions
- Confluent Cloud
- Bitnami
- AWS MSK
- Plaintext (development)

Production-Ready

Cross-Platform: Linux, macOS, Windows (amd64, arm64)
Docker Support: Minimal Alpine-based container (~50MB)
Kubernetes-Ready: CronJob examples for continuous monitoring
CI/CD Integration: Automated releases via GitHub Actions + GoReleaser
Security-Focused:
- Credential redaction in reports
- Terraform state redaction (passwords, API keys, secrets, Confluent Cloud keys)
- Command injection prevention
- TLS 1.2+ enforcement
- Thread-safe concurrent diagnostics
- Non-root container execution

Quick Start

A) Kafka Broker Check

# 1. Create a configuration file
cat > client.properties <<EOF
bootstrap.servers=your-broker.example.com:9092
security.protocol=SASL_SSL
sasl.mechanism=PLAIN
sasl.username=your-api-key
sasl.password=your-api-secret
EOF

# 2. Run the diagnostic
./kshark -props client.properties

# 3. Test with a specific topic (includes produce/consume)
./kshark -props client.properties -topic test-topic

B) Connector Target Probe via Connect API

# Probe a MongoDB connector's target — reads config from Kafka Connect REST API
./kshark -y --connect-url https://connect.example.com:8083 \
            --connector-name my-mongo-sink

kshark fetches the connector config, extracts the connection.uri, and probes MongoDB layer by layer (DNS -> TCP -> TLS -> Auth -> Ping -> Collection).

C) Connector Target Probe via Local Config File

# Probe a PostgreSQL target using a local connector config JSON file
cat > postgres-source.json <<EOF
{
  "name": "pg-source",
  "connector.class": "io.confluent.connect.jdbc.JdbcSourceConnector",
  "connection.url": "jdbc:postgresql://pghost:5432/mydb?sslmode=require",
  "connection.user": "pguser",
  "connection.password": "pgpass"
}
EOF

./kshark -y --connector-config postgres-source.json

D) Full Path: Kafka Broker + Connector Target

# Check both Kafka broker connectivity AND connector target in one run
./kshark -y -props client.properties \
            --connect-url https://connect:8083 \
            --connector-name my-mongo-sink \
            -topic test-topic

Quick Preset Example

# Use a preset for Confluent Cloud
./kshark --preset cc-plain -props client.properties

Installation

Option 1: Download Pre-built Binary (Recommended)

Download the latest release for your platform from the Releases page:

# Linux (amd64)
wget https://github.com/scalytics/kshark-core/releases/latest/download/kshark-linux-amd64.tar.gz
tar -xzf kshark-linux-amd64.tar.gz

# macOS (arm64 - Apple Silicon)
wget https://github.com/scalytics/kshark-core/releases/latest/download/kshark-darwin-arm64.tar.gz
tar -xzf kshark-darwin-arm64.tar.gz

# Windows (amd64)
wget https://github.com/scalytics/kshark-core/releases/latest/download/kshark-windows-amd64.zip
unzip kshark-windows-amd64.zip

Verify the checksum:

sha256sum -c checksums.txt

Option 2: Build from Source

Prerequisites: Go 1.23 or newer

# Clone the repository
git clone https://github.com/scalytics/kshark-core.git
cd kshark-core

# Build
go build -o kshark ./cmd/kshark

# Verify
./kshark --version

Option 3: Docker

# Pull the image (when published)
docker pull ghcr.io/scalytics/kshark-core:latest

# Or build locally
docker build -t kshark:latest .

# Run with mounted configuration
docker run -v $(pwd):/config kshark:latest -props /config/client.properties

Usage

Basic Commands

# Basic connectivity check
./kshark -props client.properties

# Check with topic validation
./kshark -props client.properties -topic my-topic

# Include produce/consume test
./kshark -props client.properties -topic my-topic

# Skip confirmation prompt (for automation)
./kshark -props client.properties -y

# Adjust global timeout
./kshark -props client.properties -timeout 120s

# Adjust Kafka metadata timeout
./kshark -props client.properties -kafka-timeout 20s

# Adjust produce/consume timeout
./kshark -props client.properties -op-timeout 30s

# Adjust produce/consume timeouts independently
./kshark -props client.properties -produce-timeout 20s -consume-timeout 45s

# Control probe read start offset
./kshark -props client.properties -start-offset latest

# Select partition balancer for probes
./kshark -props client.properties -topic my-topic -balancer rr

# Run all layers regardless of failures (full diagnostic mode)
./kshark -props client.properties -topic orders -probe-direction=full

# Force neighborhood port scan (even on success)
./kshark -props client.properties -topic orders -neighborhood

# Create diagnostics bundle with Terraform state
./kshark -props client.properties -topic orders \
    -bundle -tf-state=terraform.tfstate

# Generate HTML report
./kshark -props client.properties -topic my-topic
# Report saved to: reports/analysis_report_<hostname>_<timestamp>.html

Premium Features (Requires license.key)

# AI-powered analysis
./kshark -props client.properties -topic my-topic --analyze

# Export to JSON
./kshark -props client.properties -json report.json

Using Presets

# Confluent Cloud
./kshark --preset cc-plain -props client.properties

# AWS MSK with IAM
./kshark --preset self-scram -props client.properties

# Local development (no security)
./kshark --preset plaintext -props client.properties

Command-Line Flags

Flag	Description	Default	Example
`-props`	Path to properties file	(optional*)	`-props config.properties`
`-topic`	Comma-separated topics to test	(optional)	`-topic orders,payments`
`-group`	Consumer group for probe	(ephemeral)	`-group kshark-probe`
`--preset`	Configuration preset	(none)	`--preset cc-plain`
`-timeout`	Global timeout for entire scan	60s	`-timeout 120s`
`-kafka-timeout`	Kafka metadata/dial timeout	10s	`-kafka-timeout 20s`
`-op-timeout`	Produce/consume timeout	10s	`-op-timeout 30s`
`-produce-timeout`	Produce timeout (overrides `-op-timeout`)	(none)	`-produce-timeout 20s`
`-consume-timeout`	Consume timeout (overrides `-op-timeout`)	(none)	`-consume-timeout 45s`
`-start-offset`	Probe read start offset (`earliest	latest`)	`earliest`
`-balancer`	Probe partition balancer (`least	rr	random`)
`-diag`	Enable traceroute/MTU diagnostics	true	`-diag=false`
`-probe-direction`	Probe direction: `up` (fail-fast) or `full` (all layers)	`up`	`-probe-direction=full`
`-neighborhood`	Force port neighborhood scan (auto on TCP failure)	false	`-neighborhood`
`-neighborhood-ports`	Custom ports for neighborhood scan	`80,443,9092,...`	`-neighborhood-ports=443,9092,5432`
`-bundle`	Create diagnostics bundle (.tar.gz)	(none)	`-bundle` or `-bundle=out.tar.gz`
`-tf-state`	Terraform state file for bundle (redacted)	(none)	`-tf-state=terraform.tfstate`
`-tf-plan`	Terraform plan output for bundle (redacted)	(none)	`-tf-plan=plan.txt`
`-log`	Write detailed scan log to file	auto	`-log /tmp/kshark.log`
`--analyze`	Enable AI analysis	false	`--analyze`
`-no-ai`	Skip AI analysis even if enabled	false	`-no-ai`
`-provider`	AI provider name from `ai_config.json`	(default)	`-provider openai`
`-json`	Export to JSON file	(none)	`-json output.json`
`-y`	Skip confirmation prompt	false	`-y`
`--version`	Show version info	-	`--version`
`--connect-url`	Kafka Connect REST API URL	(none)	`--connect-url https://connect:8083`
`--connector-name`	Connector name to probe via Connect API	(none)	`--connector-name my-sink`
`--connector-config`	Local connector config JSON file	(none)	`--connector-config mongo.json`
`--connect-basic-auth`	user:pass for Connect API (or `KSHARK_CONNECT_AUTH` env)	(none)	`--connect-basic-auth admin:secret`
`--connect-bearer-token`	Bearer token for Connect API (or `KSHARK_CONNECT_TOKEN` env)	(none)
`--connect-ca-cert`	CA cert PEM for Connect API TLS	(none)

*-props is optional when using connector-only mode (--connect-url or --connector-config).

Connector Probe

kshark can probe the database targets that Kafka Connect connectors read from or write to. It reads the connector configuration (either from the Connect REST API or a local JSON file), extracts the connection parameters, and tests connectivity layer by layer.

Supported Connectors

Connector Type	Database	Protocol
MongoDB Sink/Source (`MongoSinkConnector`, `MongoSourceConnector`)	MongoDB / Atlas	MongoDB Wire Protocol
JDBC Source/Sink with `jdbc:postgresql://` URL	PostgreSQL	PostgreSQL Wire Protocol v3
JDBC Source/Sink with `jdbc:db2://` URL	IBM DB2	DRDA Wire Protocol
JDBC Source/Sink with `jdbc:mysql://` URL	MySQL	MySQL Wire Protocol
JDBC Source/Sink with `jdbc:sqlserver://` URL	SQL Server	TDS Wire Protocol
JDBC Source/Sink with `jdbc:oracle://` URL	Oracle	Oracle Net Protocol
Redis Sink/Source (`RedisSinkConnector`)	Redis	RESP Protocol
Elasticsearch Sink (`ElasticsearchSinkConnector`)	Elasticsearch	HTTP REST

Probe Layers

Each database target is probed through these layers:

L3-DNS       Resolve hostname
L4-TCP       TCP connection to host:port
L5-6-TLS     TLS handshake (if configured)
L7-Auth      Database authentication (SCRAM, MD5, DRDA SECCHK)
L7-Ping/DB   Database accessibility check
L7-Collection Collection/table existence (optional)

Example Output

=== Connector Probe: my-mongo-sink ===
  Type: com.mongodb.kafka.connect.MongoSinkConnector
  Target: mongodb:27017
  Database: testdb | Collection: events

  L3-DNS       OK    Resolved to 10.0.1.1
  L4-TCP       OK    Connected in 0ms
  L5-6-TLS     SKIP  Plain connection (no TLS)
  L7-Auth      OK    Authentication succeeded
  L7-Ping      OK    Database 'testdb' responded to ping
  L7-Collection OK   Collection 'events' is accessible

Config Source Options

Mode	Flags	Use when
Connect API	`--connect-url` + `--connector-name`	Connect cluster is reachable
Local file	`--connector-config file.json`	Connect API is not available
API + fallback	All three flags	Try API first, fall back to file

Environment Variables

Avoid putting credentials in shell history:

export KSHARK_CONNECT_AUTH="admin:secret"    # instead of --connect-basic-auth
export KSHARK_CONNECT_TOKEN="eyJhbG..."      # instead of --connect-bearer-token

Neighborhood Scan & Restriction Detection

When TCP connectivity to a Kafka port fails, kshark automatically probes nearby ports and protocols to classify the type of network restriction.

How It Works

TCP FAIL on port 9092
  ├─ Port Scan: 80, 443, 9092, 9093, 9094, 8081, 8083
  ├─ ICMP Check: ping host
  └─ Classification: selective_port_filtering / host_unreachable / ...

Example Output

❌  kafka          host.cloud:9092       L4-TCP   TCP connect failed: timeout
⚠️  neighborhood   host.cloud            Diag     Port scan: 80=OPEN, 443=OPEN, 9092=BLOCKED, 9093=BLOCKED | ICMP: OPEN (8ms)
    ↳ Hint: selective_port_filtering [confidence: high] Open TCP ports 9092-9094 in firewall/NSG/Security Group.

Restriction Classifications

Pattern	Classification	Confidence
Kafka ports blocked, 443 open	`selective_port_filtering`	high
All ports + ICMP blocked	`host_unreachable`	high
All TCP blocked, ICMP open	`all_tcp_blocked`	high
Connection refused (not timeout)	`service_not_listening`	high
All ports open	`no_network_restriction`	high

Usage

# Auto-triggered on TCP failure (default when -diag=true)
./kshark -props client.properties -topic orders

# Force neighborhood scan even on success (audit mode)
./kshark -props client.properties -topic orders -neighborhood

# Custom port list
./kshark -props client.properties -neighborhood -neighborhood-ports=443,9092,5432

Diagnostics Bundle

Package all diagnostic artifacts into a portable .tar.gz archive for sharing with support teams.

Bundle Contents

kshark-diag-<hostname>-<timestamp>/
├── report.json                      # Full kshark report
├── kshark.log                       # Run log
├── config/client.properties.redacted
├── terraform/
│   ├── terraform.tfstate.redacted   # Secrets → [REDACTED]
│   └── terraform-plan.txt           # If --tf-plan used
├── context/
│   ├── os.txt, arch.txt, hostname.txt
│   ├── resolv.conf.txt              # DNS config
│   ├── interfaces.txt               # Network interfaces
│   └── routes.txt                   # Routing table
└── MANIFEST.md                      # SHA256 checksums

Usage

# Basic bundle (report + logs + configs + system context)
./kshark -props client.properties -topic orders -y -bundle

# Bundle with Terraform state (auto-redacted)
./kshark -props client.properties -topic orders -y \
    -bundle -tf-state=terraform.tfstate

# Custom output path
./kshark -props client.properties -y \
    -bundle=/tmp/diag.tar.gz -tf-state=terraform.tfstate -tf-plan=plan.txt

After the scan, kshark prints export commands based on your environment:

Diagnostics bundle created: ./kshark-diag-bastion01-20260326-140000.tar.gz

Export commands:
  # SCP to local machine:
  scp user@bastion01:/path/to/kshark-diag-bastion01-20260326-140000.tar.gz .

  # Docker copy from container:
  docker cp <container>:/path/to/kshark-diag-bastion01-20260326-140000.tar.gz .

  # Kubectl copy from pod:
  kubectl cp <namespace>/<pod>:/path/to/kshark-diag-bastion01-20260326-140000.tar.gz ./kshark-diag.tar.gz

Terraform State Redaction

All sensitive values are automatically redacted:

Passwords, secrets, API keys, tokens
Private keys, certificates
Connection strings (userinfo portion)
Confluent Cloud-specific keys (kafka_api_key, schema_registry_api_secret, etc.)

Configuration

Properties File Format

kshark uses standard Java properties format, compatible with Kafka client configurations:

# Broker connection
bootstrap.servers=broker1.example.com:9092,broker2.example.com:9092

# Security protocol
security.protocol=SASL_SSL

# SASL configuration
sasl.mechanism=SCRAM-SHA-256
sasl.username=your-username
sasl.password=your-password

# TLS configuration
ssl.ca.location=/path/to/ca-cert.pem
ssl.certificate.location=/path/to/client-cert.pem
ssl.key.location=/path/to/client-key.pem

# Optional: Schema Registry
schema.registry.url=https://schema-registry.example.com
basic.auth.user.info=sr-key:sr-secret

# Optional: REST Proxy
rest.proxy.url=https://rest-proxy.example.com

Supported Configuration Options

See Configuration Guide for complete list.

AI Configuration (Optional)

For AI-powered analysis, create ai_config.json:

{
  "provider": "openai",
  "api_key": "sk-...",
  "api_endpoint": "https://api.openai.com/v1/chat/completions",
  "model": "gpt-4"
}

Or use environment variables:

export KSHARK_AI_PROVIDER=openai
export KSHARK_AI_API_KEY=sk-...

Integration Testbed

A complete Docker Compose testbed is included for end-to-end testing:

cd testbed/
docker compose up -d                          # Start all services
docker compose exec kshark /run-tests.sh      # Run 10 integration tests
docker compose exec kshark /run-tests.sh --skip-db2  # Skip DB2 (Apple Silicon)
docker compose down -v                        # Cleanup

Services: Kafka (KRaft), Kafka Connect (MongoDB + JDBC plugins), MongoDB 7.0, PostgreSQL 16, IBM DB2 11.5.

See testbed/TESTBED-SPEC.md for details.

Documentation

Comprehensive documentation is available in the docs/ directory:

Document	Description
ARCHITECTURE.md	System architecture, components, and design patterns
FEATURES.md	Complete feature list and usage examples
DEPLOYMENT.md	Deployment guides for Docker, Kubernetes, and CI/CD
SECURITY.md	Security audit, OWASP analysis, and recommendations

Quick Links

Architecture Overview: docs/ARCHITECTURE.md
Feature Documentation: docs/FEATURES.md
Deployment Guide: docs/DEPLOYMENT.md
Security Best Practices: docs/SECURITY.md
API Documentation: GoDoc

Architecture

kshark uses a layered testing approach to systematically validate connectivity:

┌─────────────────────────────────────────┐
│  L3: Network Layer                      │
│  • DNS Resolution                       │
│  • Hostname to IP mapping               │
└─────────────────────────────────────────┘
                  ↓
┌─────────────────────────────────────────┐
│  L4: Transport Layer                    │
│  • TCP Connection                       │
│  • Latency Measurement                  │
└─────────────────────────────────────────┘
                  ↓
┌─────────────────────────────────────────┐
│  L5-6: Security Layer                   │
│  • TLS Handshake                        │
│  • Certificate Validation               │
│  • Expiry Monitoring                    │
└─────────────────────────────────────────┘
                  ↓
┌─────────────────────────────────────────┐
│  L7: Application Layer                  │
│  • Kafka Protocol                       │
│  • SASL Authentication                  │
│  • Metadata Retrieval                   │
│  • Produce/Consume Test                 │
└─────────────────────────────────────────┘
                  ↓
┌─────────────────────────────────────────┐
│  L7: Connector Targets (optional)       │
│  • MongoDB (SRV, SCRAM, Ping, Coll)     │
│  • PostgreSQL (Wire Protocol v3)        │
│  • DB2 (DRDA Wire Protocol)             │
└─────────────────────────────────────────┘
                  ↓
┌─────────────────────────────────────────┐
│  Diagnostics                            │
│  • Traceroute / Path Analysis           │
│  • MTU Discovery + PMTU Correlation     │
│  • Neighborhood Scan (on TCP failure)   │
│  • Restriction Classification           │
└─────────────────────────────────────────┘
                  ↓
┌─────────────────────────────────────────┐
│  Diagnostics Bundle (optional)          │
│  • Redacted Terraform State             │
│  • System Context (DNS, routes, IPs)    │
│  • Export: scp / docker cp / kubectl cp │
└─────────────────────────────────────────┘

For detailed architecture information, see ARCHITECTURE.md.

Project Structure

kshark-core/
├── cmd/kshark/            # Main application (15 focused source files)
│   ├── main.go            # Entry point, CLI flags, watch mode
│   ├── scan.go            # Scan orchestration, config, REST proxy
│   ├── ai.go              # AI analysis prompt building + API client
│   ├── auth.go            # SASL authentication (PLAIN, SCRAM, JAAS)
│   ├── bundle.go          # Diagnostics bundle, Terraform redaction
│   ├── connector.go       # Connector probe orchestration
│   ├── diagnostics.go     # Traceroute, MTU, PMTU correlation
│   ├── httpcheck.go       # Schema Registry, REST Proxy checks
│   ├── kafka.go           # Kafka dialer, metadata, produce/consume
│   ├── neighborhood.go    # Port neighborhood scan, restriction classification
│   ├── properties.go      # Properties file loading, presets
│   ├── report.go          # Report model, JSON/HTML output
│   ├── ssrf.go            # SSRF two-tier protection
│   ├── tls.go             # TLS config, certificate validation
│   └── util.go            # Shared helpers, logging, redaction
├── internal/              # Internal packages
│   ├── probe/             # Database probing engine
│   │   ├── types.go       # ProbeTarget, ProbeStep, Prober interface
│   │   ├── common.go      # Shared DNS/TCP/TLS probe helpers
│   │   ├── mongodb.go     # MongoDB prober (mongo-driver)
│   │   ├── postgres.go    # PostgreSQL prober (pgx)
│   │   └── db2.go         # DB2 prober (custom DRDA wire protocol)
│   └── connectapi/        # Kafka Connect integration
│       ├── client.go      # Connect REST API client (SSRF-protected)
│       ├── config_parser.go # Connector type detection + config extraction
│       ├── jdbc_url.go    # JDBC URL parser (DB2, PostgreSQL)
│       └── redact.go      # Credential redaction
├── testbed/               # Docker integration testbed
│   ├── docker-compose.yml # Kafka + Connect + MongoDB + PG + DB2
│   ├── configs/           # Connector config examples
│   ├── init/              # Database initialization scripts
│   └── run-tests.sh       # 10 automated integration tests
├── web/templates/         # HTML report templates
├── docs/                  # Documentation
├── Dockerfile             # Container build definition
├── go.mod                 # Go module (kafka-go, mongo-driver, pgx)
├── LICENSE                # Apache 2.0 license
└── README.md              # This file

Examples

Example Output

Console Output:

╔═══════════════════════════════════════════════════════════════╗
║                    kshark Diagnostic Report                    ║
║                   Target: broker.example.com                   ║
╚═══════════════════════════════════════════════════════════════╝

[L3: Network Layer]
✓ DNS Resolution: broker.example.com → 192.0.2.1 (45ms)

[L4: Transport Layer]
✓ TCP Connection: 192.0.2.1:9092 established (123ms)

[L5-6: Security Layer]
✓ TLS Handshake: TLS 1.3 successful (234ms)
✓ Certificate: CN=broker.example.com, expires in 87 days
⚠ Certificate Expiry: Certificate expires in <90 days

[L7: Application Layer]
✓ Kafka Metadata: 3 brokers, 42 partitions
✓ Topic Visibility: 'orders' found with 6 partitions
✓ Produce/Consume: Message round-trip successful (456ms)

[Diagnostics]
✓ Network Path: 8 hops, avg latency 45ms
✓ MTU: 1500 bytes (standard Ethernet)

Summary: 9 OK, 1 WARN, 0 FAIL

Docker Example

# Build image
docker build -t kshark:latest .

# Run diagnostic
docker run --rm \
  -v $(pwd)/client.properties:/config/client.properties:ro \
  -v $(pwd)/reports:/reports \
  kshark:latest -props /config/client.properties -topic test -y

# Check the report
open reports/analysis_report_*.html

Kubernetes CronJob Example

apiVersion: batch/v1
kind: CronJob
metadata:
  name: kafka-health-check
spec:
  schedule: "*/15 * * * *"  # Every 15 minutes
  jobTemplate:
    spec:
      template:
        spec:
          containers:
          - name: kshark
            image: kshark:latest
            args: ["-props", "/config/client.properties", "-topic", "health-check", "-y"]
            volumeMounts:
            - name: config
              mountPath: /config
              readOnly: true
          volumes:
          - name: config
            secret:
              secretName: kafka-credentials
          restartPolicy: OnFailure

Troubleshooting

Common Issues

Problem: DNS resolution fails

Solution: Check DNS server configuration, verify hostname is correct
Check: nslookup your-broker.example.com

Problem: TLS handshake fails

Solution: Verify TLS version support, check certificate chain
Check: openssl s_client -connect broker.example.com:9092 -showcerts

Problem: SASL authentication fails

Solution: Verify credentials, check SASL mechanism matches broker config
Common issues: Wrong mechanism (PLAIN vs SCRAM), incorrect credentials

Problem: "license.key required" error

Solution: AI analysis and JSON export are premium features
Option 1: Obtain a license.key file
Option 2: Use standard console/HTML output (free)

Debug Mode

For verbose output, check the generated HTML report which includes:

Full configuration (credentials redacted)
Detailed error messages
Network diagnostic output
Timestamp and version information

Contributing

We welcome contributions! Please see our contributing guidelines:

Fork the repository
Create a feature branch (git checkout -b feature/amazing-feature)
Commit your changes (git commit -m 'Add amazing feature')
Push to the branch (git push origin feature/amazing-feature)
Open a Pull Request

Development Setup

# Clone your fork
git clone https://github.com/scalytics/kshark-core.git
cd kshark-core

# Install dependencies
go mod download

# Run tests (if available)
go test ./...

# Build
go build -o kshark ./cmd/kshark

# Test locally
./kshark -props client.properties.example

Security

For security concerns and vulnerability reports, please see SECURITY.md.

Security Features:

Credential redaction in all outputs (including sasl.jaas.config)
SSRF protection: two-tier model (DENY loopback/link-local, WARN RFC1918 for PrivateLink)
Redirect-based SSRF bypass prevention (CheckRedirect handler)
Credential scrubbing in connector probe error messages
Connect API auth via environment variables (KSHARK_CONNECT_AUTH, KSHARK_CONNECT_TOKEN)
Command injection prevention
TLS 1.2+ enforcement
Non-root container execution

Security Notes:

Credentials stored in plain text configuration files (use file permissions 0600)
RFC1918 addresses are allowed (with warning) since PrivateLink targets are common
See SECURITY.md for detailed analysis

Code Quality

Metric	Value
Statement coverage (`cmd/kshark`)	61.6%
Statement coverage (`internal/connectapi`)	75.7%
Statement coverage (`internal/probe`)	72.3%
Test functions	261 unit + 3 fuzz
`go vet` warnings	0
Race conditions (`-race`)	0
Source files	15 (cmd) + 11 (internal)
Largest file	685 lines (`main.go`)

Key quality properties:

SSRF protection on all HTTP paths (29 call sites) with two-tier model (DENY loopback, WARN RFC1918)
Fuzz testing on JAAS parser, properties loader, SSRF URL validator, JDBC URL parser
Context cancellation propagated through all probe functions (DNS, TCP, TLS)
Mutex-safe report writes (sync.Mutex in Report struct)
Credential redaction in reports, bundles, AI prompts, and ConfigEcho

Roadmap

Completed:

Modular architecture (14 focused source files, internal packages)
Connector target probing (MongoDB, DB2, PostgreSQL)
SSRF protection (two-tier model)
Enhanced AI analysis prompt (layered reasoning, confidence, severity)
Integration testbed (Docker Compose, 10 automated tests)
Credential redaction hardening (sasl.jaas.config, bearer tokens)
Probe direction control (--probe-direction=up|full)
Neighborhood scan — port-level restriction detection with classification
PMTU black hole correlation (ICMP vs TCP cross-reference)
Diagnostics bundle with Terraform state redaction
Thread-safe concurrent diagnostics (parallel traceroute/MTU)
CI/CD pipeline (GitHub Actions, GoReleaser, SBOM, cosign signing)
MySQL, SQL Server, Oracle connector probes (wire protocol, zero dependencies)
Redis, Elasticsearch connector probes
Broker discovery scan (advertised listener mismatch detection)
Layered exit codes (1=DNS, 2=TCP, 3=TLS, 4=App, 5=Diag)
kshark doctor (diagnostic tool availability check)
--watch mode (re-run scan on interval)
kshark diff (compare two scan results)
kshark trend (historical scan analysis)

License

This project is licensed under the Apache License 2.0. See the LICENSE file for complete details.

Copyright 2024-2026 Scalytics GmbH and kshark Contributors

Licensed under the Apache License, Version 2.0 (the "License");
you may not use this file except in compliance with the License.
You may obtain a copy of the License at

    http://www.apache.org/licenses/LICENSE-2.0

Unless required by applicable law or agreed to in writing, software
distributed under the License is distributed on an "AS IS" BASIS,
WITHOUT WARRANTIES OR CONDITIONS OF ANY KIND, either express or implied.
See the License for the specific language governing permissions and
limitations under the License.

Acknowledgments

Built with segmentio/kafka-go
MongoDB probing via mongo-driver (pure Go)
PostgreSQL probing via pgx (pure Go)
DB2 probing via custom DRDA wire protocol implementation (no CGO)
Inspired by network diagnostic tools like tcpdump, wireshark, and netcat
Special thanks to the Kafka community

Support

Documentation: docs/
Issues: GitHub Issues
Discussions: GitHub Discussions

Made with ❤️ for the Kafka community

Built for AI Agents and Teams of Collaborating Experts

Table of Contents

Key Features

Comprehensive Connectivity Testing

AI-Powered Analysis (Premium)

Developer-Friendly

Production-Ready

Quick Start

A) Kafka Broker Check

B) Connector Target Probe via Connect API

C) Connector Target Probe via Local Config File

D) Full Path: Kafka Broker + Connector Target

Quick Preset Example

Installation

Option 1: Download Pre-built Binary (Recommended)

Option 2: Build from Source

Option 3: Docker

Usage

Basic Commands

Premium Features (Requires license.key)

Using Presets

Command-Line Flags

Connector Probe

Supported Connectors

Probe Layers

Example Output

Config Source Options

Environment Variables

Neighborhood Scan & Restriction Detection

How It Works

Example Output

Restriction Classifications

Usage

Diagnostics Bundle

Bundle Contents

Usage

Terraform State Redaction

Configuration

Properties File Format

Supported Configuration Options

AI Configuration (Optional)

Integration Testbed

Documentation

Quick Links

Architecture

Project Structure

Examples

Example Output

Docker Example

Kubernetes CronJob Example

Troubleshooting

Common Issues

Debug Mode

Contributing

Development Setup

Security

Code Quality

Roadmap

License

Acknowledgments

Support
