Create and manage instance groups with Kubernetes.

instance-manager simplifies the creation of worker nodes from within a Kubernetes cluster, create InstanceGroup objects in your cluster and instance-manager will provision the actual machines and bootstrap them to the cluster.

Worker nodes in Kubernetes clusters work best if provisioned and managed using a logical grouping. Kops introduced the term “InstanceGroup” for this logical grouping. In AWS, an InstanceGroup maps to an AutoScalingGroup.

Given a particular cluster, there should be a way to create, read, upgrade and delete worker nodes from within the cluster itself. This enables use-cases where worker nodes can be created in response to Kubernetes events, InstanceGroups can be automatically assigned to namespaces for multi-tenancy, etc.

instance-manager provides this Kubernetes native mechanism for CRUD operations on worker nodes.

Installation

You must first have atleast one instance group that was manually created, in order to host the instance-manager pod.

kubectl create namespace instance-manager
kubectl apply -n instance-manager -f https://raw.githubusercontent.com/keikoproj/instance-manager/master/docs/04_instance-manager.yaml

For more examples and usage, please refer to the Installation Reference Walkthrough.

Usage example

Currently supported provisioners

Provisioner	Description	Supported?
eks-cf	provision nodes on EKS using cloudformation	✅
eks-tf	provision nodes on EKS using terraform	⚠️🔜
ec2-kops	provision nodes on AWS using Kops	⚠️🔜

To create an instance group, submit an InstanceGroup spec to the controller.

Sample spec

apiVersion: instancemgr.keikoproj.io/v1alpha1
kind: InstanceGroup
metadata:
  name: hello-world
spec:
  # provision for EKS using Cloudformation
  provisioner: eks-cf
  # upgrade strategy
  strategy:
    type: rollingUpdate
  # provisioner configuration
  eks-cf:
    # autoscaling group size
    minSize: 1
    maxSize: 3
    configuration:
      # extra kubelet arguments for taints / labels
      bootstrapArguments: --register-with-taints=my-taint-key=my-taint-value:NoSchedule --node-labels=my-label=true
      # an existing ec2 keypair name
      keyPairName: my-key
      # an EKS compatible AMI
      image: ami-089d3b6350c1769a6
      instanceType: m5.large
      volSize: 20
      # the name of the EKS cluster
      clusterName: my-eks-cluster
      subnets:
      - subnet-1a2b3c4d
      - subnet-4d3c2b1a
      - subnet-0w9x8y7z
      securityGroups:
      - sg-q1w2e3r4t5y6u7i8
      # tags to append to all created resources
      tags:
        - key: mykey
          value: myvalue

Submit & Verify

$ kubectl create -f instance_group.yaml
instancegroup.instancemgr.keikoproj.io/hello-world created

$ kubectl get instancegroups
NAME          STATE                MIN   MAX   GROUP NAME   PROVISIONER   AGE
hello-world   ReconcileModifying   1     3                  eks-cf        10s

some time later, once the cloudformation stacks are created

$ kubectl get instancegroups
NAME          STATE   MIN   MAX   GROUP NAME              PROVISIONER   AGE
hello-world   Ready   1     3     autoscaling-group-name  eks-cf        4m

$ kubectl get nodes
NAME                                        STATUS   ROLES         AGE    VERSION
ip-10-10-10-10.us-west-2.compute.internal   Ready    system        2h     v1.12.7
ip-10-10-10-20.us-west-2.compute.internal   Ready    hello-world   32s    v1.12.7

For more examples and usage, please refer to the Installation Reference Walkthrough.

❤ Contributing ❤

Please see CONTRIBUTING.md.

Developer Guide

Please see DEVELOPER.md.
