Solving Many Optimal Transport Problems in Parallel — POT Python Optimal Transport 0.9.6 documentation

Note

Go to the end to download the full example code.

In some situations, one may want to solve many OT problems with the same structure (same number of samples, same cost function, etc.) at the same time.

In that case using a for loop to solve the problems sequentially is inefficient. This example shows how to use the batch solvers implemented in POT to solve many problems in parallel on CPU or GPU (even more efficient on GPU).

# Author: Paul Krzakala <paul.krzakala@gmail.com>
# License: MIT License

# sphinx_gallery_thumbnail_number = 1

Computing the Cost Matrices

We want to create a batch of optimal transport problems with \(n\) samples in \(d\) dimensions.

To do this, we first need to compute the cost matrices for each problem.

Note

A straightforward approach would be to use a Python loop and ot.dist(). However, this is inefficient when working with batches.

Instead, you can directly use ot.batch.dist_batch(), which computes all cost matrices in parallel.

Solving the Problems

Once the cost matrices are computed, we can solve the corresponding optimal transport problems.

Note

One option is to solve them sequentially with a Python loop using ot.solve(). This is simple but inefficient for large batches.

Instead, you can use ot.batch.solve_batch(), which solves all problems in parallel.

reg = 1.0
max_iter = 100
tol = 1e-3

# Naive approach
results_values_list = []
for i in range(n_problems):
    res = ot.solve(M_list[i], reg=reg, max_iter=max_iter, tol=tol, reg_type="entropy")
    results_values_list.append(res.value_linear)

# Batched approach
results_batch = ot.solve_batch(
    M=M_batch, reg=reg, max_iter=max_iter, tol=tol, reg_type="entropy"
)
results_values_batch = results_batch.value_linear

assert np.allclose(np.array(results_values_list), results_values_batch, atol=tol * 10)

Comparing Computation Time

We now compare the runtime of the two approaches on larger problems.

Note

The speedup obtained with ot.batch can be even more significant when computations are performed on a GPU.

from time import perf_counter

n_problems = 128
n_samples = 8
dim = 2
reg = 10.0
max_iter = 1000
tol = 1e-3

samples_source = np.random.randn(n_problems, n_samples, dim)
samples_target = samples_source + 0.1 * np.random.randn(n_problems, n_samples, dim)


def benchmark_naive(samples_source, samples_target):
    start = perf_counter()
    for i in range(n_problems):
        M = ot.dist(samples_source[i], samples_target[i])
        res = ot.solve(M, reg=reg, max_iter=max_iter, tol=tol, reg_type="entropy")
    end = perf_counter()
    return end - start


def benchmark_batch(samples_source, samples_target):
    start = perf_counter()
    M_batch = ot.dist_batch(samples_source, samples_target)
    res_batch = ot.solve_batch(
        M=M_batch, reg=reg, max_iter=max_iter, tol=tol, reg_type="entropy"
    )
    end = perf_counter()
    return end - start


time_naive = benchmark_naive(samples_source, samples_target)
time_batch = benchmark_batch(samples_source, samples_target)

print(f"Naive approach time: {time_naive:.4f} seconds")
print(f"Batched approach time: {time_batch:.4f} seconds")

Naive approach time: 0.2942 seconds
Batched approach time: 0.0094 seconds

Gromov-Wasserstein

The ot.batch module also provides a batched Gromov-Wasserstein solver.

Note

This solver is not equivalent to calling ot.solve_gromov() repeatedly in a loop.

Key differences:

ot.solve_gromov() Uses the conditional gradient algorithm. Each inner iteration relies on an exact EMD solver.
ot.batch.solve_gromov_batch() Uses a proximal variant, where each inner iteration applies entropic regularization.

As a result:

ot.solve_gromov() is usually faster on CPU
ot.batch.solve_gromov_batch() is slower on CPU, but provides better objective values.

from ot import solve_gromov, solve_gromov_batch


def benchmark_naive_gw(samples_source, samples_target):
    start = perf_counter()
    avg_value = 0
    for i in range(n_problems):
        C1 = ot.dist(samples_source[i], samples_source[i])
        C2 = ot.dist(samples_target[i], samples_target[i])
        res = solve_gromov(C1, C2, max_iter=1000, tol=tol)
        avg_value += res.value
    avg_value /= n_problems
    end = perf_counter()
    return end - start, avg_value


def benchmark_batch_gw(samples_source, samples_target):
    start = perf_counter()
    C1_batch = ot.dist_batch(samples_source, samples_source)
    C2_batch = ot.dist_batch(samples_target, samples_target)
    res_batch = solve_gromov_batch(
        C1_batch, C2_batch, reg=1, max_iter=100, max_iter_inner=50, tol=tol
    )
    avg_value = np.mean(res_batch.value)
    end = perf_counter()
    return end - start, avg_value


time_naive_gw, avg_value_naive_gw = benchmark_naive_gw(samples_source, samples_target)
time_batch_gw, avg_value_batch_gw = benchmark_batch_gw(samples_source, samples_target)

print(f"{'Method':<20}{'Time (s)':<15}{'Avg Value':<15}")
print(f"{'Naive GW':<20}{time_naive_gw:<15.4f}{avg_value_naive_gw:<15.4f}")
print(f"{'Batched GW':<20}{time_batch_gw:<15.4f}{avg_value_batch_gw:<15.4f}")

Method              Time (s)       Avg Value
Naive GW            0.0897         0.7070
Batched GW          0.3746         0.2914

In summary: no more for loops!

import matplotlib.pyplot as plt

fig, ax = plt.subplots(figsize=(4, 4))
ax.text(0.5, 0.5, "For", fontsize=160, ha="center", va="center", zorder=0)
ax.axis("off")
ax.plot([0, 1], [0, 1], color="red", linewidth=10, zorder=1)
ax.plot([0, 1], [1, 0], color="red", linewidth=10, zorder=1)
plt.show()

Total running time of the script: (0 minutes 0.818 seconds)
