Create and load model

To create a model that you can open with cppflow you just need to create a tf.Module or a tf.keras.Model and save it. Using the functional API of keras this is as easy as:

import tensorflow as tf


input = tf.keras.Input(shape=(5,))

output = tf.keras.layers.Dense(5, activation=tf.nn.relu)(input)
output = tf.keras.layers.Dense(1, activation=tf.nn.sigmoid)(output)
model = tf.keras.Model(inputs=input, outputs=output)

model.compile()

# Export the model to a SavedModel
model.save('model', save_format='tf')

Now a new directory named model is created, and it contains the saved model. You can open it from cppflow using the model class, to then feed it with a tensor to obtain the output.

#include <iostream>
#include "cppflow/cppflow.h"


int main() {

    auto input = cppflow::fill({10, 5}, 1.0f);
    cppflow::model model("../model");
    auto output = model(input);

    std::cout << output << std::endl;

    return 0;
}

Inference on EfficientNet

For this example we use a pretrained EfficientNet network that is available in Keras applications. Running the following code will create a model directory with the definition of the EfficientNet and its weights.

import tensorflow as tf

model = tf.keras.applications.EfficientNetB0()

# Export the model to a SavedModel
model.save('model', save_format='tf')

Now we can open the model from cppflow and perform inference with a real image.

Inference on EfficientNet from c++ with a picture of a cat

We can load the image using cppflow::read_file and cppflow::decode_jpeg. Then we have to convert it to float and feed it to the network.

#include <iostream>
#include "cppflow/cppflow.h"


int main() {

    auto input = cppflow::decode_jpeg(cppflow::read_file(std::string("../my_cat.jpg")));
    input = cppflow::cast(input, TF_UINT8, TF_FLOAT);
    input = cppflow::expand_dims(input, 0);
    cppflow::model model("../model");
    auto output = model(input);

    std::cout << "It's a tiger cat: " << cppflow::arg_max(output, 1) << std::endl;

    return 0;
}

To see the prediction of the network we apply cppflow::arg_max to the ouput and it will show the number of the predicted class, which corresponds with a tiger cat.

Multi input/output model

For this example we will create a Keras model that takes two inputs and produce two outputs:

import tensorflow as tf

input_1 = tf.keras.Input(shape=(5,), name='my_input_1')
input_2 = tf.keras.Input(shape=(5,), name='my_input_2')

x1 = tf.keras.layers.Dense(5, activation=tf.nn.relu)(input_1)
x2 = tf.keras.layers.Dense(5, activation=tf.nn.relu)(input_2)

output_1 = tf.keras.layers.Dense(1, activation=tf.nn.sigmoid, name='my_outputs_1')(x1)
output_2 = tf.keras.layers.Dense(1, activation=tf.nn.sigmoid, name='my_outputs_2')(x2)

model = tf.keras.Model(inputs=[input_1, input_2], outputs=[output_1, output_2])

model.compile()

# Export the model to a SavedModel
model.save('model', save_format='tf')

Now, we will inspect the model with the saved_model_cli to retrieve the name of the operations, and to know how to call the model.

$ saved_model_cli show --dir model
'serve'
$ saved_model_cli show --dir model --tag_set serve
SignatureDef key: "__saved_model_init_op"
SignatureDef key: "serving_default"
$ saved_model_cli show --dir model --tag_set serve --signature_def serving_default
The given SavedModel SignatureDef contains the following input(s):
  inputs['my_input_1'] tensor_info:
      dtype: DT_FLOAT
      shape: (-1, 5)
      name: serving_default_my_input_1:0
  inputs['my_input_2'] tensor_info:
      dtype: DT_FLOAT
      shape: (-1, 5)
      name: serving_default_my_input_2:0
The given SavedModel SignatureDef contains the following output(s):
  outputs['my_outputs_1'] tensor_info:
      dtype: DT_FLOAT
      shape: (-1, 1)
      name: StatefulPartitionedCall:0
  outputs['my_outputs_2'] tensor_info:
      dtype: DT_FLOAT
      shape: (-1, 1)
      name: StatefulPartitionedCall:1
Method name is: tensorflow/serving/predict

From this output we can see that there are two inputs (serving_default_my_input_1:0 and serving_default_my_input_2:0) and two outputs (StatefulPartitionedCall:0 and StatefulPartitionedCall:1). You can run the model specifying multiple inputs as a vector of tuples <name of the input, input tensor and multiple outputs as a vector with the name of the outputs:

#include <iostream>
#include "cppflow/cppflow.h"

int main() {

    auto input_1 = cppflow::fill({10, 5}, 1.0f);
    auto input_2 = cppflow::fill({10, 5}, -1.0f);
    cppflow::model model("../model");

    auto output = model({{"serving_default_my_input_1:0", input_1}, {"serving_default_my_input_2:0", input_2}}, {"StatefulPartitionedCall:0", "StatefulPartitionedCall:1"});

    std::cout << "output_1: " << output[0] << std::endl;
    std::cout << "output_2: " << output[1] << std::endl;
    return 0;
}
